<vaadin-form-layout>

<vaadin-form-layout> is a Web Component providing configurable responsive layout for form elements.

<vaadin-form-layout>

  <vaadin-form-item>
    <label slot="label">First Name</label>
    <input class="full-width" value="Jane">
  </vaadin-form-item>

  <vaadin-form-item>
    <label slot="label">Last Name</label>
    <input class="full-width" value="Doe">
  </vaadin-form-item>

  <vaadin-form-item>
    <label slot="label">Email</label>
    <input class="full-width" value="jane.doe@example.com">
  </vaadin-form-item>

</vaadin-form-layout>

It supports any child elements as layout items.

By default, it makes a layout of two columns if the element width is equal or wider than 40em, and a single column layout otherwise.

The number of columns and the responsive behavior are customizable with the responsiveSteps property.

Spanning Items on Multiple Columns

You can use colspan or data-colspan attribute on the items. In the example below, the first text field spans on two columns:

<vaadin-form-layout>

  <vaadin-form-item colspan="2">
    <label slot="label">Address</label>
    <input class="full-width">
  </vaadin-form-item>

  <vaadin-form-item>
    <label slot="label">First Name</label>
    <input class="full-width" value="Jane">
  </vaadin-form-item>

  <vaadin-form-item>
    <label slot="label">Last Name</label>
    <input class="full-width" value="Doe">
  </vaadin-form-item>

</vaadin-form-layout>

Explicit New Row

Use the <br> line break element to wrap the items on a new row:

<vaadin-form-layout>

  <vaadin-form-item>
    <label slot="label">Email</label>
    <input class="full-width">
  </vaadin-form-item>

  <br>

  <vaadin-form-item>
    <label slot="label">Confirm Email</label>
    <input class="full-width">
  </vaadin-form-item>

</vaadin-form-layout>

Auto Responsive Mode

To avoid manually dealing with responsive breakpoints, Form Layout provides an auto-responsive mode that automatically creates and adjusts fixed-width columns based on the container's available space.

The columnWidth and maxColumns properties define the width of each column and the maximum number of columns that the component can create. By default, the component creates up to 10 columns, each with a width of 12em or the value of the --vaadin-field-default-width CSS custom property, if defined.

The auto-responsive mode is disabled by default. To enable it for an individual instance, set the auto-responsive attribute:

<vaadin-form-layout auto-responsive>
  <vaadin-text-field label="First Name"></vaadin-text-field>
  <vaadin-text-field label="Last Name"></vaadin-text-field>
  <vaadin-text-area label="Address" colspan="2"></vaadin-text-area>
</vaadin-form-layout>

You can also enable it for all instances by enabling the following feature flag before <vaadin-form-layout> elements are added to the DOM:

window.Vaadin.featureFlags.defaultAutoResponsiveFormLayout = true;

Organizing Fields into Rows

By default, each field is placed on a new row. To organize fields into rows, you can either:

1. Manually wrap fields into <vaadin-form-row> elements.

2. Enable the autoRows property to let Form Layout automatically arrange fields in available columns, wrapping to a new row when necessary. <br> elements can be used to force a new row.

Here is an example of using <vaadin-form-row>:

<vaadin-form-layout auto-responsive>
  <vaadin-form-row>
    <vaadin-text-field label="First Name"></vaadin-text-field>
    <vaadin-text-field label="Last Name"></vaadin-text-field>
  </vaadin-form-row>
  <vaadin-form-row>
    <vaadin-text-area label="Address" colspan="2"></vaadin-text-area>
  </vaadin-form-row>
</vaadin-form-layout>

Expanding Columns and Fields

You can configure Form Layout to expand columns to evenly fill any remaining space after all fixed-width columns have been created. To enable this, set the expandColumns property to true.

Also, Form Layout can stretch fields to make them take up all available space within columns. To enable this, set the expandFields property to true.

Customizing Label Position

By default, Form Layout displays labels above the fields. To position labels beside fields, you need to wrap each field in a <vaadin-form-item> element and define its labels on the wrapper. Then, you can enable the labelsAside property:

<vaadin-form-layout auto-responsive labels-aside>
  <vaadin-form-row>
    <vaadin-form-item>
      <label slot="label">First Name</label>
      <vaadin-text-field></vaadin-text-field>
   </vaadin-form-item>
   <vaadin-form-item>
     <label slot="label">Last Name</label>
      <vaadin-text-field></vaadin-text-field>
    </vaadin-form-item>
  </vaadin-form-row>
  <vaadin-form-row>
    <vaadin-form-item colspan="2">
      <label slot="label">Address</label>
      <vaadin-text-area></vaadin-text-area>
    </vaadin-form-item>
  </vaadin-form-row>
</vaadin-form-layout>

With this, FormLayout will display labels beside fields, falling back to the default position above the fields only when there isn't enough space.

CSS Properties Reference

The following custom CSS properties are available for styling:

Custom CSS property	Description	Default
--vaadin-form-layout-column-spacing	Length of the spacing between columns	2em
--vaadin-form-layout-row-spacing	Length of the spacing between rows	1em
--vaadin-form-layout-label-width	Width of the label when labels are displayed aside	8em
--vaadin-form-layout-label-spacing	Length of the spacing between the label and the input when labels are displayed aside	1em
